SAE ARP 1482C:2026-01-28

Recommendations for Fuel and Oil System Schematics (Stabilized: Jan 2026)

Summary

This document recommends and sets forth a set of symbols representing the components making up aircraft fuel and oil systems. The intended result is uniformity in system schematics so that they may be easily understood throughout the aerospace industry.

Technical characteristics

Publisher SAE International
Publication Date 01/28/2026
Page Count 11
Themes Aerospace
EAN ---
ISBN ---
Weight (in grams) ---
