SAE AIR 4094A:2016-07-18

This SAE Aerospace Information Report (AIR) supplies information on the flight control systems incorporated on various current and historic fixed wing, rotary wing, and tilt rotor aircraft. A brief description of the aircraft is followed by a description of the flight control system, some specific components, drawings of the internal arrangement, block diagrams, and schematics. System operation redundancy management is also presented.
