ISO/IEC SYMBOL:2026 DB
Graphical symbols for use on equipment
Preview
Summary
12-month subscription to ISO/IEC SYMBOL Database
ISO/IEC SYMBOL DB contains more than 5200 graphical symbols published in IEC 60417 and ISO 7000. These symbols are used to identify equipment or a part of equipment, indicate functional states, designate connections, provide information on packaging or provide instruction for the operation of the equipment. The symbols are available in GIF and vectorized PDF formats. The database provides classified views by shape, function, and application, as well as a search facility.
ISO/IEC SYMBOL DB contains more than 5200 graphical symbols published in IEC 60417 and ISO 7000. These symbols are used to identify equipment or a part of equipment, indicate functional states, designate connections, provide information on packaging or provide instruction for the operation of the equipment. The symbols are available in GIF and vectorized PDF formats. The database provides classified views by shape, function, and application, as well as a search facility.
Technical characteristics
| Publisher | International Electrotechnical Commission (IEC) |
| Publication Date | 03/04/2026 |
| Release Date | 03/04/2026 |
| Edition | 1 |
| Page Count | 0 |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
