ISO 6412-2:2017 (R2023)
Active , Reaffirmed Standard
Most Recent

ISO 6412-2:2017 (R2023)

Technical product documentation — Simplified representation of pipelines
Part 2: Isometric projection

Summary

ISO 6412-2:2017 specifies supplementary rules, in addition to the general rules given in ISO 6412-1, applicable to isometric representation. Isometric representation is used where it is necessary to show the essential features clearly in three dimensions.

Notes

90.93 : Norme internationale confirmée

Technical characteristics

Publisher International Organization for Standardization (ISO)
Publication Date 12/07/2017
Confirmation Date 06/12/2023
Edition 2
Page Count 12
EAN ---
ISBN ---
Weight (in grams) ---
