IEC 61188-7:2009
Printed boards and printed board assemblies - Design and use - Part 7: Electronic component zero orientation for CAD library construction
Preview
Summary
IEC 61188-7:2009 establishes a consistent technique for the description of electronic component orientation, and their land pattern geometries. This facilitates and encourages a common data capture and transfer methodology amongst and between global trading partners.
Technical characteristics
| Publisher | International Electrotechnical Commission (IEC) |
| Publication Date | 05/26/2009 |
| Release Date | 05/26/2009 |
| Cancellation Date | 04/10/2017 |
| Edition | 1 |
| Page Count | 40 |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
