Active
Standard
Most Recent
IEC 61169-8:2007
Radio-frequency connectors - Part 8: Sectional specification - RF coaxial connectors with inner diameter of outer conductor 6,5 mm (0,256 in) with bayonet lock - Characteristic impedance 50 O (type BNC)
Preview
Summary
IEC 61169-8:2007 It is a sectional specification (SS), provides information and rules for the preparation of detail specifications (DS) for RF coaxial connectors which may preferably be used with RF cables 60096 IEC 50-3 of IEC 60096-2. These connector patterns are for low power, quick connect/disconnect applications using a bayonet type coupling mechanism and are commonly known as type "BNC". It constitutes a technical revision. It differs from IEC 60169-8 primarily in that it contains:
- a new Clause 7: Quality assessment procedures and
- a new Clause 8: Instructions for preparation of detail specifications. Futhermore this IEC 61169-8 refers to IEC 61169-1 whereas IEC 60169-8 referred to IEC 60169-1.
- a new Clause 7: Quality assessment procedures and
- a new Clause 8: Instructions for preparation of detail specifications. Futhermore this IEC 61169-8 refers to IEC 61169-1 whereas IEC 60169-8 referred to IEC 60169-1.
Technical characteristics
| Publisher | International Electrotechnical Commission (IEC) |
| Publication Date | 02/16/2007 |
| Release Date | 02/16/2007 |
| Edition | 1 |
| Page Count | 70 |
| Themes | Quality assurance |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
