IEC 60431:1973
Dimensions of square cores (RM-cores) made of magnetic oxides and associated parts
Preview
Summary
Specifies the dimensions that are of importance for mechanical interchangeability for a preferred range of square cores (RM-cores) made of magnetic oxides, the dimensional limits for wound coil formers to be used with these cores and the locations of their terminal pins on a 2,54 mm printed wiring grid in relation to the base outlines of the cores.
Technical characteristics
| Publisher | International Electrotechnical Commission (IEC) |
| Publication Date | 01/01/1973 |
| Release Date | 01/01/1973 |
| Cancellation Date | 01/01/1983 |
| Edition | 1 |
| Page Count | 11 |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
No products.
Previous versions
11/10/1995
Superseded
Historical
10/05/1996
Superseded
Historical
01/01/1973
Superseded
Historical
01/01/1983
Superseded
Historical
