ASME Y14.31-2014 (R2019)
Undimensioned Drawings
Preview
Summary
This Standard establishes the requirements for undimensioned drawings which graphically define items with true geometry view(s) and predominantly without the use of dimensions.
Technical characteristics
| Publisher | American Society of Mechanical Engineers (ASME) |
| Publication Date | 01/01/2014 |
| Release Date | 06/11/2014 |
| Edition | 2014 |
| Page Count | 44 |
| Themes | Drafting |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
