ASD-STAN prEN 3646-003 (10/01/2016)
Aerospace series - Connectors, electrical, circular, bayonet coupling, operating temperature 175 °C or 200 °C continuous - Part 003: Receptacle, square flange mounting - Product standard
Preview
Summary
This standard defines the characteristics of square flange receptacles of the family of bayonet coupling circular connectors, intended for use in an operating temperature range of -65 °C to 175 °C or 200 °C continuous. It applies to models defined in Table 3. For contact, filler plugs and rear accessories associated with this receptacle see EN 3646-002. For plugs and protective covers, see EN 3646-008 and EN 3646-009 respectively.
Technical characteristics
| Publisher | Association des industries aérospatiales et de défense de l'Europe - Normalisation |
| Publication Date | 10/01/2016 |
| Edition | P2 |
| Page Count | 7 |
| EAN | --- |
| ISBN | --- |
| Weight (in grams) | --- |
